KissCAM V1.0
Our simplest camera. Perfect for 1U Cubesats with limited download bandwidth. Get a beautiful image in a single UHF ground station pass – even with lost packets.
From £ 800.00
Specification Highlights
- Colour, 480 x 360 pixels
- 10g, 38 x 20 x 17 mm
- Stock wide-angle, replaceable M12 lens
- 115200 baud UART interface (RS422)
- 3.3 to 5V supply range
- -20 to +60°C
- Flight Heritage. See our photo gallery!
KissCAM V2.0
Flight heritage on commercial missions, this model offers 1.2 MP resolution and non-volatile image storage. Take beautiful images with minimal integration effort.
From £ 1200.00
Specification Highlights
- Colour/Monochrome, 1280 x 960 pixels
- 10g, 38 x 20 x 17 mm
- M12 lens, filters and global shutter options
- 115200 baud UART interface (RS422/RS485)
- 3.3 to 5V supply range
- -20 to +60°C
- Flight Heritage. See our photo gallery!
KissCAM Pro
Need more storage? KissCAM Pro extends the heritage KissCAM architecture with 1GB+ of non-volatile memory. Available with various lenses and optical filters.
From £ 2400.00
Specification Highlights
- Up to 1920 x 1080 pixel resolution
- 1GB+ onboard memory
- 12g, 45 x 35 x 17 mm
- M12 lens and optical filter options
- RS422/RS485/CAN interface
- 3V3 to 5V supply
- -20 to +60°C
Star Tracker ST1
Fully autonomous and with an optional integrated baffle, KissCAM ST makes incorporating a star tracker into your mission simpler and lower-cost than ever before.
From £ 7500.00
Specifications with Baffle
- 3σ Accuracy (XY/Z): 0.01/0.06°
- 2Hz update rate
- 12.8 x 12.8 degree field of view
- 35 degree sun exclusion
- 160g, 43 x 49 x 64 mm
- 330 mW
- RS422/RS485 interface
MVP Aerospace
